Nested parallelism, Java 8 parallel streams, Bug in the ForkJoinPool framework.

Java 8 Parallel Streams Deadlocking

The Java 8 parallel streams api supports parallel processing of operators and parallel foreach loops. However, it appears as if the backend executor framework, the fork/join pool, has a problem with nested parallel loops: If you use nested parallel streams, e.g. like
IntStream.range(0,24).parallel().forEach(i -> {
  // do some heavy work here
  IntStream.range(0,100).parallel().forEach(j -> {
    // do some work here
  });
});

you may observe very poor performance at high CPU usage. For example, runnning the test program at NestedParallelForEachBenchmark.java I get the following results:

Timing for test cases (parallelism set to 2):
inner loop parallel             = 41,18 +/- 2,99 (min: 33,14 , max: 45,59) [CPU Time: 106,00] (number of threads in F/J pool: 8)
inner loop sequential           = 27,61 +/- 0,50 (min: 26,62 , max: 28,61) [CPU Time: 76,91] (number of threads in F/J pool: 2)
inner loop parallel with bugfix = 26,99 +/- 0,81 (min: 25,75 , max: 28,77) [CPU Time: 77,73] (number of threads in F/J pool: 2)
(test cases were run independent with 20 warm up runs and 20 test runs on an Intel i7@2.6 GHz).


In addition, using synchronization may lead to (unexpected) deadlocks. For example, the following code will result in a deadlock:
IntStream.range(0,24).parallel().forEach(i -> {
  // do some heavy work here
  synchronized(this) {
    IntStream.range(0,100).parallel().forEach(j -> {
      // do some work here
    });
  }
});

In this test case we generate 24 parallel tasks to make some calculation. At one point we need to synchronize (assume we need to access some state). There is only one thread entering the synchronized() part. Inside the synchronized part we evaluate some function in parallel (why not, all the other threads are waiting anyway), but that is fine (there is no nested locking). Some might suspect that - given that all tasks are submitted to a common thread pool - there are no more threads to calculate the inner loop in parallel. However, even if there are no more free workers, there is at least one active thread, namely that one which entered the synchronized {} block, and we expect that parallel execution defaults to in-line sequential execution if there are no additional threads available.
The parallel streams use a common ForkJoinPool as a backend, and this behavior is implemented in the ForkJoinTask: it distinguishes between a ForkJoinWorkerThread and the main Thread and all tasks which cannot be completed by a ForkJoinWorkerThread can run (sequentially) on the main Thread.
Also note, that the documentation of the backend ForkJoinPool states that

"The pool attempts to maintain enough active (or available) threads by dynamically adding, suspending, or resuming internal worker threads, even if some tasks are stalled waiting to join others. However, no such adjustments are guaranteed in the face of blocked IO or other unmanaged synchronization."

- but a deadlock would only be expected if the number of available threads is exhausted (and we are far below that number). So while synchonize should be avoided, the documentation of the ForkJoinPool does not forbit synchronization.
Even without the synchronize the bug will lead to performance issues (see a corresponding post on stackoverflow).

The Bug

The test whether a task is running on a main thread (the creator of that loop) or running on a worker is performed via the line (401 in ForkJoinTask of 1.8u5 (Java 8))
((t = Thread.currentThread()) instanceof ForkJoinWorkerThread)
so it just tests if the currentThread is of type ForkJoinWorkerThread. But for a nested loop, the calling thread (the creator) could itself be of type ForkJoinWorkerThread, because it is a worker of the outer loop. In that case the inner loops task is joined with another outer loop task (which is currently waiting for the synchronized lock) and this results in a deadlock.

Reproducing the bug

To reproduce the bug and check the claim:
  1. Run the program NestedParallelForEachAndSynchronization.java (see below) in a debugger. It will hang in a deadlock in the last test case (a simple nested loop with inner synchonization).
  2. In the debugger suspend all threads and check where theses threads are waiting.
  3. You will find out that all threads wait for the synchronize lock inside the outer loop and that lock is owned by one of the threads, lets call that thread ForkJoinPool.commonPool-worker-7.
  4. If you check ForkJoinPool.commonPool-worker-7 then you see that he waits of the synchronize lock too, but he is already inside the inner loop. Now, lets check why a pice of code inside the synchronize waits for the lock: You see that the wait() is issued by the awaitJoin() in line 402 of ForkJoinTask. This is wrong, instead that task should have done an externalWaitDone(). Explanation: That task is the main task of the inner loop, i.e., a task of the outer loop that created the inner loop, but (due to a bug) that tasks considers itself as a forked worker (of the inner loop) and creates a join - effectively joining with the outer loop’s task. The problem is that if the inner loop is running on a forked worked of the outer loop, we cannot distinguish forked (inner loop’s) worker from main threads because line 401 is always true.
  5. Double Checking: If the explanation in 4 would be correct, the problem would go away if we fix line 401 (and also all other corresponding tests). To fix this we change the type of the thread containing the inner loop from ForkJoinWorkerThread to Thread (by creating a wrapper). Indeed: this fixed that deadlock and greatly improved performance. The second test case in NestedParallelForEachAndSynchronization.java does this.
For a complete test demonstrating the deadlock and the workaround see: NestedParallelForEachAndSynchronization.java

Perfomance Problem induced by the Bug

The faulty join may lead to performance problems. For a complete test demonstrating the performance issue see NestedParallelForEachBenchmark.java or NestedParallelForEachTest.java.

Epilog

Nested parallelism may occure quite natural: Consider
IntUnaryOperator func = (i) -> IntStream.range(0,100).parallel().map(j -> i*j).sum();
- a definition of a function i -> func(i), which is defined as a sum of i*j and which is internally calculated in parallel. and then do
IntStream.range(0,100).parallel().map(func).sum();
(a discrete approximation of a two dimensional integral). Of course, this code (and other such problems) can be reformulated into a non-nested version, but assuming that you like to encapsulate the internal definition of func, the nesting is a consequence of abstraction.

I first encountered that bug via a deadlock introduced by using a Semaphore inside the outer loop (e.g. like a blocking IO). I have posted this to stackoverflow (and, following a suggestion on SO, to the concurrency-interest mailing list). The discussion started by that post then focussed on the question whether using a Semaphore and/or nested parallel loops would be a good design practice.
So far my conclusion is:
  • Currently, nesting of parallel streams should be avoided since it has a performance issues.
  • Nesting of parallel streams with inner synchronized has to be avoided, because a real risk of (otherwise unexpected) deadlocks.
  • Currently the use of dedicated Executor frameworks is best to implement nested parallelism. However, using dedicated Executors has the disadvantage that is is much harder to maintain a global level of parallelism.

Monte-Carlo Methods on GPGPU with Applications to Mathematical Finance


There will be a workshop on
Monte-Carlo Methods on GPGPU with Applications to Mathematical Finance
at the LMU quantLab. For details see http://www.fm.mathematik.uni-muenchen.de/news/gpu_workshop_news/index.html

Implementation of the YEARFRAC function in Excel (2013), LibreOffice (4.1) and OpenOffice (4.0)

Setting up a demo spreadsheet for a workshop, I - accidentally - found my self comparing the calculation of day count fractions using finmath lib's Java implementation with the calculation using the spreadsheets YEARFRAC function.

To my surprise, the implementation of this function is surprisingly unclear and inconsistent.

Some facts about YEARFRAC in Excel, LibreOffice, OpenOffice.

The spreadsheet function YEARFRAC(Date start, Date end, Integer basis) implement five different methods for calculating day count fractions, depending on the value of basis = 0, 1, 2, 3, 4. According to the "documentation" these methods are 30U/360 (basis=0), ACT/ACT (basis=1), ACT/360 (basis=2), ACT/365 (basis=3), 30E/360.

  • The Excel implementation of "ACT/ACT", i.e. YEARFRAC(start, end,4) does not agree with - the very common - ACT/ACT ISDA. I saw a claim that Excel implements ACT/ACT AFB, but I could not verify this claim.
  • I have a reimplementation of all 4 daycount conventions implemented by Excel. These are available in finmath lib. They are: (Note: The implementations above have been benchmarked against Excel using some 10000's test cases.)
  • The implementation of Excel ACT/ACT does not agree with ACT/ACT ISDA, which you can find at DayCountConvention_ACT_ACT_ISDA.java
  • The implementation of Excel ACT/ACT does not agree with ACT/ACT AFB which you can find at DayCountConvention_ACT_ACT_AFB.java
  • The implementation of Excel ACT/ACT and LibreOffice ACT/ACT do not agree, although it agrees in many cases. In some cases the values are off by a factor of 365/366, i.e., 0,3%
  • The implementation of LibreOffice ACT/ACT (i.e. YEARFRAC with basis=1) differs from the implementation in Excel (a bug report has been filed to the LibreOffice group).
  • The implementation of OpenOffice ACT/ACT differs from the implementation in Excel and from the implementation in LibreOffice (a bug report has been filed to the OpenOffice group)
You find a bunch of implementations of day count conventions in finmath lib. The claims above may be veryfied using the spreadsheet at finmath.net/topics/daycountingandschedules.

The implementation of YEARFRAC ACT/ACT does not make sense from a financial point of view.

Since the YEARFRAC may be interpreted as accrual factors for interest rate periods we may consider a few desirable properties. Surprisingly Excel fails in many trivial requirements:

Property 1: Additivity. The yearfrac should be additive. For Excel this is not the case: YEARFRAC(30.12.2011, 04.01.2012, 1) is not equal to YEARFRAC(30.12.2011, 01.01.2012, 1) + YEARFRAC(01.01.2012, 04.01.2012, 1).

Property 2: Proportional Leap Year Attribution. Assume that 8 quaterly periods span exactly two years (DD.MM.YYYY to DD.MM.(YYYY+2) and assume that YYYY+1 is a leap year. Since the numerator of act/act measures actual days, we expect that the denominator will have 4 times 365 and 4 times 366. For Excel and LibreOfffice this is not the case. In Excel only 3 of the 8 Periods 01.07.99, 01.10.99, 01.01.00, 01.04.00, 01.07.00, 01.10.00, 01.01.01, 01.04.01, 01.07.01 receive a denominator of 366. In LibreOffice (4.1) 5 of the 8 Periods get a denominator of 366.

Note: ACT/ACT ISDA fulfills both properties.

LIBOR Market Model: Spreadsheet and Source Code


Spreadsheet and code for the LIBOR market model added to finmath.net. Java source code availabe from the finmath lib subversion repository.

screenshot-modelscreenshot-swaption

Curve Calibration: Spreadsheet and Source Code


Demo spreadsheet for the calibration of curves (discount curves, forward curves) to interest rate swaps added to the spreadsheets section of finmath.net. Java source code availabe from the finmath lib subversion repository.

CurveCalibrationScreenshot

First Steps Towards a LaTeX to iBooks Conversions

Today I made a little experiment with iBooks Author 2.0. The new version allows to insert formulas by typing LaTeX, but currently there is no way to automatically convert a LaTeX document to a iBooks Author document.

However, the following seems to be promising:
  • Create a simple documents (basically empty, some text) and insert a LaTeX formula.
  • Save the document, for example as Test.iba
  • Rename the document to Test.zip and in terminal type unzip Test.zip
  • From the unzipped folder Test open the file Test/index.xml.
  • In index.xml you will find your LaTeX formula at some place. Now, try to edit the latex within the index.xml (that is you edit the LaTeX source).
  • Save the file, zip the folder back to Test.zip (using zip in the Terminal not from Finder) and rename it back to Test.iba.
  • If you open the modified Test.iba you will see the document with the new formula.
Thus, it apears to be possible to write a LaTeX to IBA (iBooks Authors) converter.

Vorlesung 2012/2013: Numerische Methoden der Finanzmathematik

Informationen zur Vorlesung
Numerische Methoden der Finanzmathematik.

finden sich unter http://www.christian-fries.de/finmath/lecture12-13/.

Computational Finance: Job Offer at LMU Department of Mathematics

The Ludwig-Maximilian-University Munich, Department of Mathematics, is advertising a

Post Doctoral or Doctoral position

in the field of financial and insurance mathematics with special IT duties. The position is commencing at the earliest convenience for a term of 2 years with possible extension.
For details see
http://www.christian-fries.de/lmu/joboffer2012

Obba: Handling Java Objects in Excel, OpenOffice, LibreOffice and NeoOffice

obba
A new version of Obba has been released: Obba Version 3.1.5.

New in version 3.1: Support for creating objects dynamically from source code, see Class to Object Demo (movie).

Obbaprovides a bridge between spreadsheets and Java classes. With Obba, you can use spreadsheets as GUIs (Graphical User Interfaces) for your Java libraries. Compatible with Excel/Windows, OpenOffice/Win/Mac/Linux, LibreOffice/Win/Mac/Linux, NeoOffice/Mac.

Obba's main features are:Obba Diagram

  • Stateful access to almost all objects and methods running in a Java virtual machine via a fixed set of spread sheet functions.
  • Client/server support: The Java virtual machine providing the add-in may run on the same computer or a remote computer - without any change to the spreadsheet.
  • Loading of arbitrary jar or class files at runtime through a spreadsheet function.
  • Instantiation of Java objects, storing the object reference under a given object label.
  • Invocation of methods on objects referenced by their object handle, storing the handle to the result under a given object label.
  • Asynchronous method invocation and tools for synchronization, turning your spreadsheet into a multi-threaded calculation tool.
  • Allows arbitrary number of arguments for constructors or methods (avoids the limitation of the number of arguments for Excel worksheet functions).
  • Serialization and de-serialization (save Serializable objects to a file, restore them any time later).
  • All this through spreadsheet functions, without any additional line of code (no VBA needed, no additional Java code needed).

Use cases:

  • For Spreadsheet Users: Creating powerful spreadsheet calculations using external libraries, running calculations in Java.
  • For Java Developers: Testing, debugging and analyzing Java libraries with spreadsheets. Setting up unit test in spreadsheets. Using spreadsheets as GUI to your object while debugging.

Advanced Features:

  • Run Obba server (and its JVM) on one machine, while the spreadsheet (with Obba add-in) runs on another machine.
  • Obba allows to create an object from Java source code (dynamically compile source to java.lang.Class, re-load the class definition and instantiate an object from it), see Class to Object Demo (movie).

For tutorials see Obba tutorials. For a more detailed introduction see Obba documentation.

Vorlesung 2012: Finanzmathematik: Bewertungsmethoden für Zinsderivate. Vor und nach der Finanzkrise.

Information zur Vorlesung
Finanzmathematik: Theorie, Modellierung und objektorientierte Implementierung von Bewertungsmethoden für Zinsderivate.
Vor und nach der Finanzkrise.

findet sich unter http://www.christian-fries.de/finmath/lecture12/.

Obba: Handling Java Objects in Excel, OpenOffice, LibreOffice and NeoOffice

obba
A new version of Obba has been released: Obba Version 3.0.6.

Obba provides a bridge between spreadsheets and Java classes. With Obba, you can use spreadsheets as GUIs for your Java libraries; turning your Java library to platform independent spreadsheet add-ins. Compatible with Excel/Windows, OpenOffice/Win/Mac/Linux, LibreOffice/Win/Mac/Linux, NeoOffice/Mac.

Its main features are:
Obba Diagram

  • Stateful access to almost all objects and methods running in a Java virtual machine via a fixed set of spread sheet functions.

  • Client/server support: The Java virtual machine providing the add-in may run on the same computer or a remote computer - without any change to the spreadsheet.

  • Loading of arbitrary jar or class files at runtime through a spreadsheet function.

  • Instantiation of Java objects, storing the object reference under a given object label.

  • Invocation of methods on objects referenced by their object handle, storing the handle to the result under a given object label.

  • Asynchronous method invocation and tools for synchronization, turning your spreadsheet into a multi-threaded calculation tool.

  • Allows arbitrary number of arguments for constructors or methods (avoids the limitation of the number of arguments for Excel worksheet functions).

  • Serialization and de-serialization (save Serializable objects to a file, restore them any time later).

  • All this through spreadsheet functions, without any additional line of code (no VBA needed, no additional Java code needed).



For a tutorial see Obba tutorial. In this tutorial you create a Java class and a spreadsheet to fetch Stock quotes from finance.yahoo.com.

For a more detailed introduction see Obba documentation and Obba home page.

Version 3.0.6 of Obba is a major revision. It brings support for running the Java virtual machine on a different machine, i.e. via Obba, the spreadsheet may perform its Java calculations on a remote machine.

For more information see Obba's homepage.

Registering COM Add-In on 64 bit Windows (with NSIS / Wow6432Node)

If you like to register a COM add-in with a custom installer (instead of using RegAsm.exe), you can generate the keys using RegAsm.exe with the /regfile option. Thus, a straight forward way to register a COM add-in using NSIS is as follows:
  1. Use RegAsm.exe with the option /regfile to generate a list of registry entries.
  2. Create an NSIS script with the corresponding WriteRegStr entries to create these registry entries.

However, this method may not work if you like to use the installer on a 64 bit Windows 7 system to register the COM add-in for 64 bit applications. On a 64 bit system you will find some of your keys registered in the Wow6432Node, which is the part for 32 bit applications and not seen by 64 bit applications.
A workaround may be to use DLL host, however this workaround should only be used if your COM add-in is 32 bit only. The workaround will also work for COM add-ins which are 64 bit and 32 bit (compiled as "AnyCPU"), but performance will be poor.

The problem here is that NSIS creates a 32 bit installer which - per default - writes certain keys to the Wow6432Node (i.e. it registers the COM add-in for 32 bit applications). If you like to register the COM add-in for 64 bit applications (too) you have to register (again) using SetRegView 64 prior registration (search the internet for "NSIS SetRegView 64").

Note that the two version of RegAsm (one in Frameworks and one in Frameworks64) export the same registry entries when used with /regfile, but, writing to the registry, they write to the 32 bit or 64 bit view respectively.

See also http://support.microsoft.com/kb/305097 and note that registry reflection was removed in Windows 7 (see http://msdn.microsoft.com/en-us/library/aa384235.aspx )

Obba: Handling Java Objects in Excel, OpenOffice, LibreOffice and NeoOffice

obba
A new version of Obba has been released: Obba Version 2.2.15.

Obba provides a bridge from spreadsheets (Excel or OpenOffice) to Java classes via worksheet functions (UDFs), without the need to write a single line of code. With Obba, you can easily build spreadsheet GUIs to Java classes. Obba is available for Excel and OpenOffice and Obba sheets may be migrated from Excel to OpenOffice or vice versa.

For more information see Obba's homepage.

OpenOffice extension with signed JAR not working

In case you create a Java base OpenOffice extension (.oxt) and stumble across the error message:
ImplementationRegistration::registerimplementation()
InvalidRegistryException during registration (prepareRegistry(): source registry is empty)
it could be related to a signed jar.

A Java based OpenOffice extension (.oxt) using a signed JAR (inside the .oxt bundle) may produce the error above if the the corresponding IDL_Types.jar is unsigned. To produce an OXT with a signed JAR create a .keystore (using keytool) and sign the JAR at the -pre-uno-package build step:

<target name="-pre-uno-package">
   <signjar jar="${dist.jar}" alias="yourAlias" storepass="yourPassword" />
   <signjar jar="${dist.dir}/${idl_types.jar}" alias="yourAlias" storepass="yourPassword" />
</target>

More Comments on iOS 4 Multitasking

Some More Comments on iOS 4 Multitasking.

Expiration Handlers

If a process is running in background, having issued UIApplication's beginBackgroundTask before, then the process expiration handler's code following the (last) issuing of endBackgroundTask is not executed. In other words: iOS 4 does not wait until your expiration handler block is finishes. It waits for the last endBackgroundTask and terminates the app (quite ungracefully).

View Controllers

If your app enters background the active view controller does not receive a viewWillDisappear. Neither will it receive a viewWillAppear if the app enters foreground.

Application Lifecycle

On iOS 4.0 the message applicationWillTerminate is rarely send. I made some tests and found the follwoing:
  • An app will not receice applicationWillTerminate if it is in background and user selects force quit (pressing the minus sign in the list of recent apps).
  • An app will not receive applicationWillTerminate if is is in background and the user selects to shut down the device while your app is running.
  • An app will not receice applicationWillTerminate if it is in background and system shuts down due to low battery.
  • An app will receive applicationWillTerminate if it is in foreground and sytem shuts down due to low battery.
  • An app will receive applicationWillTerminate if it is in foreground and the user selects to shut down the device while your app is running.
If you like to save the state of your app you have to do so in applicationWillTerminate (for OS 2.x, 3.x and 4.x) and (!) in applicationDidEnterBackground (for OS 4.0).

A Short Note on iOS 4 (iPhone OS) Multitasking

Last weekend I checked out iOS 4, in particular its multitasking. From articles on the web I got the impression that iOS 4 multitasking isn't a real multitasking, rather a fast app switching (see, e.g., the article by Matt Neuburg as cited on daring fireball).

But: iOS 4 apps are fully multitasking with just two exceptions:
  • The iOS 4 UI event loop is single tasked, i.e. only the front app is running on the UI event loop. If app code is designed to be running on the UI event loop thread, then it is not executing if it enters background. However, this is not a big restriction. An app will not receive any UI events when running in background anyway (even on Mac OS X). If you design your iOS 4 app to be detached from the UI event loop it continues to run when put to background.
  • The OS may terminate your app when resources like memory are running low or "execution time" is used up. This is also not a big restriction. For example, on OS X if memory is running low the user is prompted to terminate an app. Also, on OS X I would terminate an app if it runs crazy and takes up all CPU time. So actually I believe it is an improvement to start thinking about rules when apps are terminated by the OS. (Note: For iOS 4 the rule which terminates an app is a bit too simple, as I will explain soon).

Apart from these restrictions you can run code in background. You can run your own run loop in background and register timers (events) with that run loop.

Background Run Loop

This is done with the following code:

  dispatch_async(dispatch_get_global_queue(DISPATCH_QUEUE_PRIORITY_DEFAULT, 0), ^{

    // Create and register your timers

    // ...

    // Create/get a run loop an run it
    // Note: will return after the last timer's delegate has completed its job
    [[NSRunLoop currentRunLoop] run];
  });

In the upcoming release of Serial Mail (Version 4.1) I have implemented a background task which sends mail via an SMTP server in background. This background task uses timers to check the response of the SMTP server an hence it is requiring a run loop. I was able to do network connections in background. Apple says that you should prepare that network connections may fail when the app is running in background (however an app needs to check for failing connections anyway).

App Termination

So this solves the first problem, that the UI thread is single threaded. What about iOS terminating your app when it runs in background: To prevent that the OS terminates the app we should tell it that we have a long running background task. Apple suggest that you mark each background tasks by calls to UIApplication's beginBackgroundTask and endBackgroundTask see the developer documentation's sample code. I haven't seen a definition of "long running", but it appears as if the app is terminated if a background task runs 10 minutes after the app has been suspended (it does not help to launch a new background task / thread from another one).

Improving the App Termination Criteria

For my app 10 minutes background task time are sufficient. There are application where you require a truly long running background process checking stuff at certain intervals, etc. However, it is clear that the multitasking introduced in IOS 4 just needs a minor tweak: it requires more sophisticated rules for terminating apps. For apps with background task a much better rule would be to consider cpu time that real time. This would for example allow apps like instapaper to check and download files in background on a regular basis (say, once a day) if that task consumes only a small amount of cpu time. The author of instapaper discussed a different solution in his blog, however I hope for a simpler one: better, transparent criteria for termination of a background apps.

Scheduled Relaunch

Another improvement of the current multitasking APIs, which is more in line with the solution in the instapaper blog, would be to include a user configurable service for scheduled relaunch of an app into background. The service should be configurable on an per app basis. Apps registering with it should bring up a dialog requesting for permission (like location service does). The service should then call a method like applicationDidLaunchToBackground. I would prefer such a solution over a myriad of specialized background services. Instead the relaunch service could take options like "relaunch when network available".

There is one strange thing about iOS 4: When the user terminates the app manually (by deleting it from the list of recently used apps) then iOS does not call your app delegates applicationWillTerminate method. I have used applicationWillTerminate to save the application's state upon termination and now that code had to move to applicationWillResignActive.

Obba: Handling Java Objects in Excel, OpenOffice and NeoOffice

obba
A new version of Obba has been released: Obba Version 1.9.34.

Obba provides a bridge from spreadsheets (Excel or OpenOffice) to Java classes via worksheet functions (UDFs), without the need to write a single line of code. With Obba, you can easily build spreadsheet GUIs to Java classes. Obba is available for Excel and OpenOffice and Obba sheets may be migrated from Excel to OpenOffice or vice versa.

For more information see Obba's homepage.

Release Notes

Version 1.9.34 of Obba brings the following changes:

  • Fixed a problem which prevented loading of some classes. The current thread's context class loader was null. This appears to be a problem with the Java plugin. A workaround was created. Note: This problem resulted in the XMLDecoder not working.
  • Fixed a problem which prevented installation of Obba for OpenOffice.
  • More improvements for OpenOffice
  • Arrays of objects can be created using obMake with a class name of ClassName[] where ClassName is the component type (see documentation for an example).
  • Added a demo sheet showing how to access data from finance.yahoo.com. Include the Java source code for the class handling the web access.

Snow Leopard 64 Bit Kernel - Switching between Apps

Snow Leopard felt slow on my MacBook Pro (5,5). Switching between apps felt sluggish. I usually run Safari, Eclipse an VMWare at the same time and often switch between these.

The MBP booted with 32 bit version of the OS X 10.6 Kernel (this is the default) - thx O.S. for the hint. To my surprise, switching to the 64 bit kernel made a big difference. Switching between apps is much (!) snappier. (I did not see any perfomance test discussing app switching!)

PS: You can boot into the 64 bit kernel by changing the file
/Library/Preferences/SystemConfiguration/com.apple.Boot.plist
to include the following Kernel Flags
<key>Kernel</key>
<string>mach_kernel</string>
<key>Kernel Flags</key>
<string>arch=x86_64</string>

How to Fetch Stock Quotes from Yahoo into Excel/OpenOffice using Java

I wrote a small tutorial on how to use Obba and a small Java class to load Yahoo stock quotes into Excel / OpenOffice. It is just an example and could easily extended to other data / web sites.

Java code and spreadsheets are included.

Obba: Handling Java Objects in Excel and OpenOffice

obba
A new version of Obba has been released: Obba Version 1.9.13.

Obba provides a bridge from spreadsheets (Excel or OpenOffice) to Java classes via worksheet functions (UDFs), without the need to write a single line of code. With Obba, you can easily build spreadsheet GUIs to Java classes. Obba is available for Excel and OpenOffice and Obba sheets may be migrated from Excel to OpenOffice or vice versa.

For more information see Obba's homepage.

Release Notes

Version 1.9.13 of Obba brings the following changes:
  • Added a window to the Obba Control Panel which visualizes the objects and their dependencies in a graph. The dependencies are determined by the objects used during construction an object.
  • Improved the handling of transient object handles.

iPhone OS App: Serial Mail

Icon512
I have ported my OS X Application "Serial Mail" to the iPhone OS. Since the iPhone OS APIs are much cleaner than the AppleScript support of OS X Mail, Serial Mail for iPhone is to some extend faster and better than its OS X counterpart. For details see the Serial Mail home page or check out Serial Mail in the iPhone App Store.

Serial Mail 4.6 released

Serial Mail
I have release an update to Serial Mail. With Serial Mail 4.6 you can add attachments to each generated messages where the attachment is specific for the recipient. In the tag the file name may contain one or two placeholders '%@' where the first placeholder is replaced by the first name and the second placeholder is replaced by the last name of the recipient.

Obba: Handling Java Objects in Excel and OpenOffice

obba
A new version of Obba has been released: Obba Version 1.8.21.

Obba provides a bridge from spreadsheets (Excel or OpenOffice) to Java classes via worksheet functions (UDFs), without the need to write a single line of code. With Obba, you can easily build spreadsheet GUIs to Java classes. Obba is available for Excel and OpenOffice and Obba sheets may be migrated from Excel to OpenOffice or vice versa.

For more information see Obba's homepage.

Release Notes

Version 1.8.21 of Obba brings the following changes:

  • Access fields of an object directly through a spreadsheet function call using 'obCall'. In this case the method name has to be dot + fieldname (e.g '.myMember').
  • Access elements of an array through a spreadsheet function call using 'obCall'. In this case the method name has to be '[]' and the argument of the call is integer specifying the index. Element of multi-dimensional arrays can be accessed likewise.
  • Vector arguments can be passed as arbitrary ranges (columns, rows or two dimensional ranges which are then flattened using row major).

Billiger surfen mit dem iPhoneSimulator


Kürzlich war ich im Hilton Hotel in Frankfurt. Dort gibt es ein WLAN von Swisscom. Geht man vom Laptop auf die Eingangsseite so wird einem ein WLAN Tarif zu 27 Euro pro 24 Stunden angeboten. Das gleiche WLAN vom iPod touch oder iPhone aus besucht bietet einem den "Smartphone Tarif" für 3 Euro pro 24 an.

Ich kaufte auf dem iPod touch den "Smartphone Tarif" und war den Tag über gut zu erreichen.

Die Neugier geweckt stellt ich auf dem Laptop (MBP) in Safari im Developer Menü mal den User Agent auf "Mobile Safari (iPod touch)". Doch es gab trotzdem nur den teuren Tarif. Es ist auch nicht möglich sich mit der User-ID und Passwort des Smartphone-Tarifes vom Laptop aus einzuloggen.

Das ändert sich, wenn man den iPhone Simulator von XCode öffnet. Von diesem aus konnte man sich mit den Zugangsdaten des Smartphone-Tarifes einloggen (über Safari im iPhone Simulator). Danach hat dann das gesamte MacBook Pro Zugang zum Internet, nicht nur der iPhone Simulator! Offensichtlich wird die Überprüfung zum Smartphone-Tarif nur auf der Login-Seite gemacht.

iPhone OS App: Presentation Assistant

PresentationAssistantIcon

After playing around with the iPhone SDK for a while I wrote an application which supports me during a presentation with intuitively visualized timing information. For details see the Presentation Assistant home page.

Tip: uid 501 does not exist in the passwd file!

I had some trouble doing sudo on a remote (OS X 10.5) machine, logged in via ssh. It turned out that if I do
ssh username@machinename.local
then I cannot do sudo on that machine (getting the error "uid 501 does not exist in the passwd file!"). Also I can no do su (getting the error "su: who are you?"). However, if I log in using
ssh -l username machinename.local
everything works fine. Just in case you stumble across this problem...

Obba: Handling Java Objects in Excel and OpenOffice

obba
A new version of Obba has been released: Obba Version 1.7.29.

Obba provides a bridge from spreadsheets (Excel or OpenOffice) to Java classes via worksheet functions (UDFs), without the need to write a single line of code. With Obba, you can easily build spreadsheet GUIs to Java classes. Obba is available for Excel and OpenOffice and Obba sheets may be migrated from Excel to OpenOffice or vice versa.

For more information see Obba's homepage.

Release Notes

This release fixes two small bugs in connection with the software registration: For OpenOffice the location where the registration is stored changed (you have to reenter registration data).

Black Moleskine notebook missing found

IMG_0769b
My black Moleskine A6 notebook which I had lost on July 13th, 2006 (!) in a hotel in New York reappeared. It came with a letter from a lady from Ireland. Not that the book is very valuable to me (it once was)..., but the unexpected kindness made me very happy.

Serial Mail 4.3 released

Serial Mail
I have release another update to Serial Mail. With Serial Mail 4.3 generated messages are send from the account set up in the template message (before, it was the default account).

Serial Mail 4.2 released

Serial Mail
I have release an update to Serial Mail. Starting with version 4.2 I reactivated the support for formatted text, images and attachments in the template. Still, due to the sloppy implementation of Apple Mail's AppleScript support, formatted templates are processed very slowly and in some cases formatting may be lost (e.g. tables).

Conditional Analytic Monte-Carlo Pricing Scheme for Auto-Callables

We renamed the paper cited in the Journal of Computational Finance 11(3) as "A semi-analytic Monte Carlo pricing scheme for auto-callable products". Its new title is "Conditional Analytic Monte Carlo Pricing Scheme for Auto-Callable Products".

Book: Mathematical Finance: Second Printing

Title_2007_wiley
Wiley released a second printing of my book. The second printing is based on Version 1.6.11 of the PDF file. It thus contains many of the error corrections listed on the errata page. In addition, I rewrote a few sections (25 pages changed), but the difference to the old version is still minor. Major improvements, like new sections will be posted to the book's update page. (The version number is printed on page v).

PS: I will donate a larger part of my 2007 net revenue to charity organizations (like the Fördergemeinschaft Deutsche Kinderherzzentren and Deutsche Krebshilfe (German Cancer Aid)). However: my net revenue is comparably small. From Wiley I get approximately $3 per book. BTW: Sorry for the price tag. I wasn't aware that the author does not have any influence on the pricing of his book.

Captain Future

cf2_400_400
Kürzlich habe ich einen Held meiner Jugend wiederentdeckt: Captain Future (danke TK). Das vermutlich Beste an der Serie ist der Soundtrack von Christian Bruhn.

Wie der Soundtrack den Eindruck der Serie prägt zeigt ein Vergleich der Intros in verschiedenen Landessprachen:


Deutschland: Heute noch gut.
http://www.youtube.com/watch?v=kq-QBPATey0

Frankreich: Klingt in meinen Ohren wie "Captain LaBoom".
http://www.youtube.com/watch?v=9wOoF_HAsqo

USA: Captain Woodstock?
http://www.youtube.com/watch?v=d_57XARGmFQ

Spanien: Klingt nach Captain Ballermann
http://www.youtube.com/watch?v=leQC1lC9z3c

Japan: Hört sich eher nach "Captain Loveboat" an.
http://www.youtube.com/watch?v=qPncFh_sR0Y

Introducing amascore 3

Three and a half year ago I started a very nice project with Oliver Dauben: amascore. Based on a collection of technologies (where some where quite hip at those days), like JSP, XML, Webservices (Amazon ECS), Java and JDBC, we created a search engine upon the Amazon product database where the ranking of the search result is calculated from an analysis of customer reviews. Here, the relative review scoring is such that a product with many 4 star reviews may rank higher that an product with only one or few 5 star reviews.

The project reached an almost final stage with amascore 2.1 in 2005. Later in 2005 we abandoned the project because our priorities shifted.

A few days ago my stuff moved to a new server, and so did amascore. The search engine wasn't running smoothly anymore and I had the choice to shut it down or to make it run. So I reviewed code, removed a lot of bugs, installed the latest JRE and the latest servlet container (tomcat), tweaked the JSP and CSS at bit.

The result is amascore version three point zero.

Sample Chapters

Sample chapters for "Mathematical Finance" are available as a free download from the book's homepage.

Joshi on LMM

Mark Joshi is giving a seminar on "Implementing the LIBOR Market Model". The seminar will take place in London, 24th-25th January 2008. For more information see the flyer. Literature: Mark's books at amzon.co.uk, amzon.com, amazon.de.

Buch (preiswert)

Bei bol.de gibt es "Mathematical Finance: Theory, Modeling, Implementation" für 77,58 69,82 Euro, derzeit deutlich preiswerter als alle anderen Bezugsmöglichkeiten.

Mathematical Finance: Picture Book

MathematicalFinancePictureBookTitle128
The "Mathematical Finance Picture Book" presents some aspects of mathematical finance in pictures. It is a companion to "Mathematical Finance: Theory, Modeling, Implementation" (which contains these figures in grayscale only).

The "Mathematical Finance Picture Book" is available as PDF.

Book: Mathematical Finance: Theory, Modeling, Implementation: Errata

Title_2007_wiley
Version 1.5 of "Mathematical Finance" is published by Wiley on August 24th. I will maintain an errata online at www.christian-fries.de/finmath/book/errata.

Buch: Mathematical Finance: Theory, Modeling, Implementation

Bei lesen.de gibt es "Mathematical Finance: Theory, Modeling, Implementation" für 82,50 Euro, also deutlich preiswerter als bei amazon.de (derzeit 106,90 Euro).

Book: Mathematical Finance: Theory, Modeling, Implementation

Version 1.5 of my book may be pre-ordered at Amazon™:


M

M
Fritz Langs Meisterwerk "M" liegt unter der Creative Commons Lizenz als Download bei archive.org vor (u.a. als MPEG2).

Mathematical Finance Lecture Notes

Title_2007_en
The translation of my lecture notes on "mathematical finance" has been completed. The manuscript still needs some proofreading and polishing. If you would like to do a payed proofreading job on the manuscript please contract me via email (a native english speaker with good knowledge of german and some knowledge of math would be an ideal candidate).

I have released version 1.4 of the manuscript (in both german and english).

For a detailed table of contents see
http://www.christian-fries.de/finmath/book.

Multi Touch

Fundachen zum Multi-Touch-Interface des iPhones (schon etwas älter):

iPod Raffle: And the winner is 0.83119106

indexnanofrontside20060912
In version 1.2 of the manuscript on Mathematical Finance I promised an iPod raffle among all that had send in comments or error reports. The raffle took place last week and the random number generator generated 0.83119106. Mapped by the inverse cumulated distribution function of the distribution of error reports that number mapped to Patrick Jappsen, a Dipl.-Math. from Bonn University. The iPod nano 2GB silver is on its way...

I am grateful to all who had send in comments or error reports. We had some nice discussions.

There will be a new iPod raffle in version 1.3, due September 2007.



iPod raffle 2006 - invoice


Serial Mail: Bug in OS X may trash your Address Book database

Serial Mail
During the last half year I had three reports of users completely losing the contents of their Address Book while working with Serial Mail. The problem is not related to Serial Mail, it is due to a bug in Mac OS X, presumably the SyncService. There are many reports of this problem in the Apple discussion group. From these reports it appears that the problem comes form a sync (like iSync) conflicting with another application trying to access the Address Book.

As a precaution when using Serial Mail, please backup your Address Book database. It is just one click to the File menu of the Address Book application.

Talk on Proxy Simulation Scheme Method

WBS
I gave a talk at the WBS 3rd Fixed Income Conference, Amsterdam, 21-22 September 2006 presenting the proxy simulation scheme method. The talk covered the "full proxy" and the "partial proxy" simulation scheme method. The first part (full proxy) had been presented at the Quantitative Methods in Finance Conference, Sydney, 2005. I have posted an updated version of the slides at www.christian-fries.de/finmath/talks/2006proxyScheme

In addition I gave a 10 min talk at the "interest rate plenary panel". If you are interest in the "foresight bias correction" mentioned there, see
www.christian-fries.de/finmath/foresightbias.

Partial Proxy Simulation Schemes for Robust Monte-Carlo Sensitivities

CMS_TARN_Swap_Gamma_vs_Shift_-_numberOfPath_5000_maxShift_50
We consider a generic framework which allows to calculate robust Monte-Carlo sensitivities seamlessly through simple finite difference approximation. The method proposed is a generalization and improvement of the proxy simulation scheme method (Fries and Kampen, 2005).

As a benchmark we apply the method to the pricing of digital caplets and target redemption notes using LIBOR and CMS indices under a LIBOR Market Model. We calculate stable deltas, gammas and vegas by applying direct finite difference to the proxy simulation scheme pricing.

The framework is generic in the sense that it is model and almost product independent. The only product dependent part is the specification of the proxy constraint. This allows for an elegant implementation, where new products may be included at small additional costs.

For more information see http://www.christian-fries.de/finmath/proxyscheme.

Mathematical Finance Lecture Notes

FinmathBookTitle_en
Version 1.3.x of the lecture notes on "mathematical finance" now contains the missing chapter on Monte-Carlo sensitivities. The calculation of Monte-Carlo sensitivities (a.k.a. Greeks) was discussed in the last two sessions of the 2005/2006 lecture. Apart from two new chapters this version contains over 100 corrections.

For a detailed table of contents see
http://www.christian-fries.de/finmath/book.

Vorlesungsskript Finanzmathematik

FinmathBookTitle
Version 1.3.x des Vorlesungsskriptes Finanzmathematik enthält nun ein Kapitel zu Monte-Carlo Sensitivitäten. Die Berechnung von Sensitivitäten (Greeks) in einer Monte-Carlo Simulation war Thema der letzten beiden Vorlesungsstunden in 2005/2006, aber zu diesem Zeitpunkt noch nicht im Skript enthalten. Ferner wurden in dieser Version ca. 100 Fehler korrigiert.

Das vollständige Inhaltsverzeichnis findet sich unter http://www.christian-fries.de/finmath/book.
